Descriptions：
Fluid-bed coater is a new style coating equipment that combined fluid-bed spraying technology and coating well. It is wide used for film slow and control releasing coating, framework slow and control releasing capsule, pellet coating, granule, powder coating, etc.
Features：
● Coating of bottom spraying, material flow In order. We can get uniform and continuous film.
● Taste masking, odor, moistureproof, antioxidation. prevent water, heat insulation, coloration and separation coating.
● Low productive cost, and the coating material is used perfectly.
● Short travel distance of fog granule and without the problem of "spray drying".
● The design of cylinder for accelerator or cone for decelerate can Coating of granule, big granule and pellets.
● The high separate, without adhere.
| Item Model | Specification | 5 | 15 | 30 | 60 | 120 | 200 | 300-1000 |
| Feeding capacity | kg/batch | 4-6 | 10-20 | 25-40 | 40-80 | 80-150 | 150-250 | Designed according to user’s demands. |
| Container volume | L | 15 | 50 | 100 | 220 | 360 | 650 | |
| Power of fan | KW | 4 | 5.5 | 7.5 | 15 | 18.5 | 22 | |
| Compressed air consumption | m3/min | 0.4 | 0.6 | 0.9 | 1.3 | 1.8 | 2.4 | |
| Steam consumption | kg/h | 50 | 64 | 85 | 181 | 250 | 330 | |
| Overall dimenstion | H1(mm) | 2600 | 2850 | 3150 | 3250 | 3500 | 3800 | |
| H2(mm) | 340 | 490 | 590 | 790 | 890 | |||
| H3(mm) | 2630 | 2930 | 3020 | 3280 | 3580 | |||
| B1(mm) | 1010 | 1160 | 1460 | 1660 | 2060 | 2260 | ||
| B2(mm) | 1560 | 1860 | 2460 | 2860 | 3660 | 4060 | ||
| φ1(mm) | 550 | 700 | 1000 | 1200 | 1600 | 1800 | ||
| φ2(mm) | 180 | 250 | 250 | 280 | 280 | 315 | ||
| L(mm) | 850 | 1550 | 1700 | 1800 | 2000 | 2100 | ||
| Remarks:Some of the parameters are for reference only. According to the condition of material,our factory has the right to change without notice. | ||||||||
