ZYG Series Spray Dryer For Traditional Chinese Medicine Production



The machine is fully sealed. All parts are made of stainless steel. Comes with a three-stage filter. Filter air to 100,000 levels. The wall cooling device is mounted on the cylinder block. Increase the wall temperature. Less than 80 ° C. An air cleaning device is installed in the drying tower. Even if you stay on the road, the product will not be scorched or deteriorated. The collection rate of the powder is greatly improved. In addition, it does not cause drug mixing or wall stickers.
Basic principle: High-speed centrifugal atomization of traditional Chinese medicine extract is an application of centrifugal atomization technology. It is a high speed atomizing dryer. The following issues have been resolved.

1. The raw material sticks to the wall and the powder collection rate is low.
2. Due to the long residence time of the raw materials on the wall, scorching and deterioration may occur.
3. It is difficult to clean and does not meet GMP requirements. 4. Low output: Model LPG-150 atomizing centrifuge can process 50-60kg / h raw material liquid.
In view of this, according to the nature and process requirements of Chinese herbal extracts, our factory has developed and designed a special desiccant for extracts of traditional Chinese medicines and obtained Chinese patent projects. Solved the historical problem of drying. Chinese herbal extracts. Dry raw materials are good in color. The dry raw material does not deteriorate. Greatly improved economic efficiency. Compared with ordinary liquefied petroleum gas high-speed atomizing dryer, it has the following characteristics:

(1). It adopts a three-stage air filter and has an intake of 100,000.
(2). The wall cooling device is used, and the inner wall temperature is above 80 °C. Even if the material stays on the wall, it will not burn.
(3). The overall volume is 3.5 times that of the standard LPG high speed atomizing dryer.
(4). The use of a quick cleaning device can meet the production requirements of the product variety.
(5). Wet dust removal, no dust, in line with GMP requirements.
(6). With an air cleaning device, the cleaning effect is satisfactory. (7). Equipped with two sets of atomizers, controlled by frequency converter.
(8). Use PLC control and display, and use frequency control.
(9). Washing equipment is available on request.
(10). Dry air sealed transport as required.

Spec ZYG-25 ZYG-50 ZYG-80 ZYG-100 ZYG-150 ZYG-200 ZYG-300
Evaporated amount of moisture kg/h 25 50 80 100 150 200 300
Treated amount of raw material liquid (kg/h) 25-34 50-68 80-108 100-135 150-203 200-270 300-406
Output of finished product (kg/h) 4.8-7.2 9.2-14 14.8-22.4 18.4-28 24-42 36.8-56.4 55-85
Solid content of damp raw material (%) 18-25
Moisture content of finished product (%) 3-5
Electric power (kw) 63 99 132 153 204 246 330
Heating source

Steam+ Electricity

Collecting way of product and its efficiency Two-grade cyclone duster or one-grade cyclone duster and one grade damp duster ≥95%
Automatic control meters and instruments Indicator of temperature of air and humidity of air exhaust, automatic temperature controller
Temperature of air in (℃) 150-200
Temperature of air out (℃) 80-100
Overall dimension


7000 8000 9800 11000 12200 14100 15000
W 4000 5000 5700 6200 7000 7800 9000


6900 7400 8000 8900 10000 11000 12000
