Details
Descriptions：
The central screw and the outer ribbon are connected to the cycloidal needle wheel reducer, and rotate at an identical revolution. In operation, the central. In operation, the central screw lifts the material from bottom to top. mean while, the ribbon with a higher linear velocity sprials to lift the material from bottom to top along the cone wall. The two kinds of motions make the material be thrown into the space tangentially. and the material effects strong convection shearing and diffusion, thus a quick mixing effect is achieved. ( the screw can also be made to a reverse one).
Technical parameters:
| Model | Total oluvme(L) | Load fcatro | Equipped opwer(kw) |
operating conditions |
Overall dimension(mm) |
Weight (kg) |
| DSH-0.3 | 0.3 | ≤0.6 | 2.2 | 常温常压粉尘密封 | 1929φ920 | 320 |
| DSH-0.5 | 0.5 | ≤0.6 | 4 | 常温常压粉尘密封 | 2322φ1124 | 410 |
| DSH-1.0 | 1.0 | ≤0.6 | 7.5 | 常温常压粉尘密封 | 2869φ1480 | 900 |
| DSH-1.5 | 1.5 | ≤0.6 | 11 | 常温常压粉尘密封 | 3140φ1633 | 1200 |
| DSH-2.0 | 2.0 | ≤0.6 | 11 | 常温常压粉尘密封 | 3489φ1900 | 1300 |
