Details
Features：
● The three kinds of heat source used for heating are steam, electricity, both steam and electricity.
● Operation temperature: steam,50-140℃,Max.150℃; electricity, 50-350℃. The temperature can be controlled automatically. Moreover it can be recorded through recorder.
● The inner wall of oven body is fully welded . Every place of transition adopts circular arc and no dead.
● The seal property of whole machine is good . Being adopted unique guide rail seal apparatus, the seal property can be guaranteed.
● The air inlet is equipped with high effective air filter and the damp exhaust outlet is equipped with middle effective air filter.
● The double doors of oven adapt mechanical interlock apparatus.
● All parts inside the oven can be assembled and disassembled quickly in order to clean conveniently.
● The control system has text display and touch screen for your choice.
● The whole machine is in conformity with the requirements of GMP.
| Parameters/Model |
Drying capacity (Kg) |
Power of fan(KW) |
Steam consumption (Kg/h) |
Drying trolly(set) |
Baking pan (PC) |
Overall dimension L×W×H(mm) | Temperature difference between up and low(℃) |
| GMP-0 | 35 | 0.45 | 8 | / | 16 | 1130×1100×1750 | ±2 |
| GMP-I | 120 | 0.45 | 18 | 2 | 48 | 2300×1200×2000 | ±2 |
| GMP-II | 240 | 0.9 | 36 | 4 | 96 | 2300×2200×2000 | ±2 |
| GMP-III | 360 | 1.35 | 54 | 6 | 144 | 3430×2200×2000 | ±2 |
| GMP-IV | 480 | 1.8 | 72 | 8 | 192 | 4460×2200×2290 | ±2 |
